ASRock Rack's SORANOD8-2L2T brings fast networking and flexible PCIe and storage to the table, built to get the most out of AMD's EPYC 8005 Sorano processors.
Server motherboards used to be an afterthought, just there to hold the CPU. ASRock Rack's SORANOD8-2L2T changes that. If you want to use all the power of AMD's EPYC 8005 "Sorano" chips, you need a board that can keep up. This isn't just a small upgrade. ASRock Rack built this board to squeeze out every bit of Zen 5 performance, with strong networking and storage options that most competitors don't offer.
The SORANOD8-2L2T is all about I/O. The "2L2T" in its name means it has two 10GbE and two 1GbE network ports, all built in. You get high-speed networking right out of the box, no extra cards needed. The board uses an Intel X710-AT2 controller for 10GbE and an Intel I210 for 1GbE. This gives you solid, enterprise-grade connections. It's the same approach seen in other new workstation hardware, as reported earlier.
Networking is just the start. The SORANOD8-2L2T has five PCIe Gen5 slots-four x16 and one x8. That matches the 96 PCIe Gen5 lanes from the EPYC 8005. You get real choice in how to use them. The top slot can switch to provide 16 SATA 6Gbps ports with a riser, which is rare. This lets you build for heavy compute or big storage. There are also two M.2 Gen5 x4 slots (for 22110 and 2280 SSDs) and two MCIO x8 connectors. You can set those MCIO ports for either PCIe Gen5 or SATA. The board supports up to 2TB of memory and up to 32 SATA drives.
The board's size is "ATX-like"-12 inches by 10 inches. It's a bit wider than standard ATX, but not as big as EEB. This means it fits most server and workstation cases, but still has room for eight DDR5 RDIMM slots. That 8-slot setup is a clear choice: you get up to 2TB of memory, but the layout means memory speed tops out at DDR5-5200. The slots are color-coded, so you can't mess up channel assignment. That saves time and avoids mistakes when installing memory.
ASRock Rack's SORANOD8-2L2T is engineered to fully leverage the AMD EPYC 8005 platform, with a focus on PCIe Gen5 density, integrated 10GbE/1GbE networking, and flexible storage options-key requirements for modern enterprise and data center deployments.
ASRock Rack's design choices show in the power delivery and layout. The board uses three ATX12V connectors-two vertical, one right-angled. A 4-pin micro-fit connector takes the place of the usual 24-pin ATX header, and there's an adapter in the box. The VRMs are cooled by simple heatsinks. There's no oversized metal here, just what you need for airflow in a server rack. This board is built for uptime, not for looks.
The rear I/O is all business. There are five RJ45 ports: two for 10GbE, two for 1GbE, and one for IPMI management through the ASPEED AST2600 BMC. You still get a DB15 VGA port, which is common in data centers. USB is kept to a minimum-two rear and two front 5Gbps USB-A ports. That fits the server-first design. Six 6-pin fan headers run along the front edge, ready for rackmount cooling setups.
There's no extra clutter here. ASRock Rack left out anything that isn't needed, focusing on giving you full access to every key feature of the EPYC 8005 platform. The result is a board that doesn't just keep up with AMD's latest chips-it helps you use them to the fullest, whether you're building a storage server or a heavy-duty workstation.
Most boards chase long feature lists or flashy extras. The SORANOD8-2L2T is different. It gives you the basics done right and lets you decide the rest. If you want to run AMD's Zen 5 in a server or workstation, this board sets a new standard for balance and focus.
